FUTURES APW121215f,12V-15V,V4.0
| Function |
S19 Pro/S19j/S19j Pro/S19 XP/S19j Pro+/S19k Pro/S19 Pro++/D9/X5
|
| Specifications |
|
| Price |
176 $/T
176 $/Unit
|
| Shipping Date |
Delivery around 15 days after payment
|
| Payment Method |
S19 Pro
S19j
S19j Pro
S19 XP
S19j Pro+
S19k Pro
S19 Pro++
D9
X5
|
Specifications
| Product Glance | |
| OUT1 | DC Voltage 12V-15V |
| Rated Current(220V input) | 267A |
| Short Circuit Protection | >10mS |
| OUT2 | DC Voltage 12.3V |
| Rated Current(220V input) | 18A |
| Voltage Accuracy | 12.2V-12.4V |
| Short Circuit Protection | >10mS |
| Input | Voltage Range 220-277V AC |
| Frequency Range | 50/60Hz |
| Power Factor | >0.99(full load) |
| Protection | Input low-voltage protection value 185-195V AC |
| Output Short Circuit | Yes |
| Overheat Protection | Yes |
| Over-current Output | 280A-402A（protection value varies under different voltage） |
| Environment | Operating Temperature -20-40℃ |
| Operating Humidity | 20%-90%RH（non--condensing） |
| Structure | Dimensions 254.6*251.6*63mm |
| Net Weight | 3.9Kg |
| Cooling System | Forced‐air cooling |
| Noise | 45dBA |
Purchasing Guidelines
NOTES
1. One account can purchase a maximum of 500 units.
2. The shipping costs, cutsoms charges, and taxes(if any) are not included in the retail price shown above.
3. After an order has been submitted, a request to cancel the order, refund any part of the ordered amount or change the ordered item(s) to different item(s) or different batch(es) will not be entertained by BITMAIN.
4. The pictures shown are for reference only; the final shipment version shall prevail.
SHIPPING DETAILS
1. The products are made in China. If shipping to the U.S., customers will need to pay tariff.
2. Shipments will be scheduled on a first-paid-first-ship basis for orders on which BITMAIN has received full payment.
3. You are responsible for any customs delays or returned shipments due to a lack of proper documentation. It's highly recommended to be aware of local customs clearance policies and to prepare all customs documentation ahead of time to avoid any customs clearance delays or unexpected costs.
Warranty
CLICK for >> Parts & Materials Ordering Notes and Warranty Information
Please read BITMAIN’s Terms & Conditions for a complete list of conditions and terms that apply to all orders placed on bitmain.com.
