ANTSPACE PTC-R Pre-Heater Module

Description

ANTSPACE PTC-R Pre-Heater Module

Are you looking for a reliable heating solution designed for hydro-cooled Bitcoin mining infrastructure? The ANTSPACE PTC-R Pre-Heater Module from Bitmain is a specialized heating device designed to maintain stable coolant temperatures in hydro-cooling systems used in ANTSPACE mining containers. It ensures that the cooling liquid reaches optimal operating temperature during cold conditions, allowing hydro-cooled miners to start and operate safely in low-temperature environments.

The ANTSPACE PTC-R Pre-Heater Module uses PTC (Positive Temperature Coefficient) heating technology, which automatically regulates heating output to prevent overheating and improve safety. The module provides rated heating power of approximately 6 kW and operates on 380–420V AC three-phase power with 50/60Hz frequency, allowing it to integrate directly with industrial mining power infrastructure.

The heater draws about 8.7A current at 400V input and uses a pipeline-type PTC heating structure consisting of two 3 kW heating elements that warm the circulating coolant inside the container’s liquid-cooling system. The unit is designed to automatically stop heating when the coolant inlet temperature reaches 25°C, while an additional safety shutdown activates if the outlet temperature approaches 50°C, ensuring safe operation.

The module operates reliably in harsh industrial environments with a working temperature range of approximately -40°C to 50°C and supports coolant flow rates of around 10 L/min. It is designed with compact industrial dimensions of roughly 339 × 188 × 200 mm and a weight of about 11 kg, making it easy to install inside ANTSPACE container racks.

With its 6 kW heating capacity, automatic thermal protection, and integration into hydro-cooling circulation systems, the ANTSPACE PTC-R Pre-Heater Module helps ensure reliable startup and stable operation of hydro-cooled Antminer deployments in cold climates and industrial mining environments.

ANTSPACE PTC-R Pre-Heater Module – Technical Specifications

• Unit Capacity: Module designed for 1 hydro-cooling container (HK3 series)
• Slots: 1 (Rack-mounted module)
• Rated Power: 10 kW
• Heating Capacity: 10 kW
• Cooling Type: Hydro-cooling (Medium heater)
• Liquid Medium: Antifreeze / Pure Water / Deionized water
• Water Flow Rate: ≥16 L/min
• Input Voltage: 380V – 415V AC (400V Rated)
• External Dimensions: 508 x 445 x 87 mm
• Net Weight: 14 kg
• Gross Weight: 17.5 kg
• Operating Temperature: -40°C to 50°C
• Operating Humidity: 10~90% RH
• Safety Protection: Overheat Protection, Prevent Dry Heating Protection
• Material: Metal / Rack-mount construction

---

Notes

• Payment accepted in USDT, USDC, BTC, or USD. The unit price and total price of the products, and the amount paid are denominated in U.S. dollars.
• The shipping costs, customs charges, and taxes(if any) are not included in the retail price shown above.
• After an order has been submitted, a request to cancel the order, refund any part of the ordered amount or change the ordered item(s) to different item(s) or different batch(es) will not be entertained by BITMAIN.
• The pictures shown are for reference only; the final shipment version shall prevail.
• The Hashrate value, Power on wall, and Power efficiency on wall are all typical values, The actual Hashrate value fluctuates by ±3%, and the actual Power on wall and Power efficiency on wall fluctuate by ±5%.
• Caution: Wrong input voltage may probably cause product damaged.

---
